Description
MAIN SPECIFICATIONS
Function: Color Copiers/MFP
Maximum Paper Size: 12 x 47 (Banner)
Speed (ppm): 30
Prints per Month: 4000
Scan Speed: 120ipm – 240ipm w/DSDP
Standard Trays: (2) 550 Sheet, 100 Sheet Multipurpose, 500 Sheet Output
Optional Trays: (2) 550 Sheet, 2000 Sheet, Envelope Tray, Stapling, Hole Punch, Fold
Technology Options: Embedded OCR, Multi-Station Follow Me Print
Specifications
Copy System Indirect Electrostatic Photographic Method/OPC/Laser Printing/
Heat Roller Fusing
Display 9” Color WVGA Touch Screen Tilting Display
Copy Speed 25/30/35 PPM (LT)
First Copy Out Color: 7.8/7.8/7.8
Monochrome: 5.9/5.9/5.9
Warm-Up Time Approx. 20 Seconds
Copy Resolution 600 x 600 dpi
Stack Feed Bypass 3.9” x 5.8” to 12” x 18”, 12” x 47” Banner, Envelope
Multiple Copying Up to 999 Copies
Paper Capacity Standard 1,200 Sheets/Max. 3,200 Sheets
Original Feed Optional 300-Sheet DSDF or 100-Sheet RADF
Scan Speed & Weights DSDF Scan: Up to 240 IPM Duplex, 120 IPM Simplex (Monochrome or Color),
Simplex: 9.3-110 lb Bond, Duplex: 9.3-110 lb Bond
RADF Scan: Up to 73 IPM (Monochrome or Color), Simplex: 9.3-41.8 lb Bond,
Duplex: 13.3-41.8 lb Bond
Max. Original Size LD
Paper Feed Sizes Drawer 1: 550 Sheets-ST-R to LD
Drawer 2: 550 Sheets-ST-R to 12” x 18”
Stack Feed Bypass: 100 Sheets-3.9” x 5.8” to 12” x 18”, 12” x 47” Banner
Opt. 550-Sheet Paper Feed Pedestal-ST-R to 12” x 18”
Opt. 550-Sheet Drawer for PFP-ST-R to 12” x 18”
Opt. Envelope Cassette for PFP-Approx. 60 Envelopes/550 Sheets-ST-R to LG
Opt. 2,000-Sheet Tandem LCF (Pedestal Type)-LT Only
Paper Weights Standard: 550 Sheets x 2-16 lb Bond-140 lb Index
Stack Feed Bypass: 100 Sheets-14 lb Bond-100 lb Cover
Opt. 550-Sheet Paper Feed Pedestal-16 lb Bond-140 lb Index
Opt. 550 Sheets Drawer for PFP-16 lb Bond-140 lb Index
Opt. Envelope Cassette for PFP-16 lb Bond-140 lb Index
Opt. 2,000-Sheet Tandem LCF (Pedestal Type)-17 lb-28 lb Bond
Duplex Standard Automatic Duplex Unit (16 lb Bond-140 lb Index)
Reproduction Ratio 25% to 400%
Max Duty Cycle Max. 75K/90K/105K Month (Color: 100%)
Max.150K/180K/210K Month (Monochrome: 100%)
Weight Approx. 166 lb
Approx. Dimensions 23” (W) x 25.2” (D) x 31” (H)
CMYK Toner Yield CMY: 33.6K, K: 38.4K @ 5%
Power Source 120 Volts, 50/60 Hz, 12 Amps
Power Consumption Maximum 1.5kW (120V)
CPU Intel Atom™ 1.33 GHz (Dual-Core)
Memory 4GB
Hard Disk Drive 320GB Self-Encrypting Drive FIPS 140-2 Validated
